Single blade cutting machine price : VS-30: 30HP(22KW) machine.....$12,000/set
| Model | VS-30 | VS-30D | VS-60 | VS-60D |
| Dimensions (L*W*H)(mm) | 2850*1900*1800 | 3050*3000*1800 | 3300*2180*2180 | 3550*3500*2200 |
| Machine Weight(kg) | 2300 | 4500 | 3200 | 6000 |
| Main Motor Power(kw) | 22kw(30HP) | 22kw(30HP)*2 | 45kw(60HP) | 45kw(60HP)*2 |
| Electricity | 3 phases,380V,50Hz(customizable) | |||
| Amperage | 86/43A | (86/43A)*2 | 172/86A | (172/86A)*2 |
| Water Consumption(m⊃3;/h) | 3.5 | 4 | 4 | 4 |
| Blade Size(mm) | 800 | 1000&1200 | ||
| Blade Speed Standard(adjustable) | Max.900rpm. | Max.780rpm. | ||
| Max.stone heigh(mm) | 0-350 | 0-450 | ||
| Saw blade adjustable distance(up/down)(mm) | 0-120 | 0-250 | ||
| Saw blade adjustable distance(back/forth)(mm) | 0-200 | 0-250 | ||
| Max.stone thickness(mm) | 20-220 | 20-270 | ||
| Conveyor Belt Length*width*thickness(mm) | 5970*280*7 | 6800*400*7 | ||
| Conveyor Belt Speed(Adjustable)(mm/min ) | 600-2450 | 600-2450 | ||
| Max.Cutting Depth(mm) | 280 | 350-450 | ||
