30HP 60HP Bestlink Veneer Stone Saw Cutting Machine
BESTLINK
The machine is a monolithic structure with compact structure and convenient installation and transportation. The main control components are all international brand components, and the cutting main motor and cutting conveyor belt are all stepless speed regulation. The working mode of the machine adopts the continuous cutting mode of the pipeline , which is mainly usedfor cutting the plane of irregular elliptical stones such as goose warm stone.
| Model | VS-30(30HP) | VS-60(60HP) |
| Dimensions (L*W*H)(mm) | 2850*1900*1800 | 3300*2180*2180 |
| Machine Weight(kg) | 2300 | 3200 |
| Main Motor Power(kw) | 22 | 45 |
| Electricity | 3 phases,380V,50Hz(customizable) | |
| Amperage | 86/43A | 172/86A |
| Water Consumption(m³/h) | 3.5 | 4 |
| Blade Size(mm) | 800 | 1000&1200 |
| Blade Speed Standard(adjustable) | Max.900rpm. | Max.780rpm. |
| Max.stone heigh(mm) | 0-350 | 0-450 |
| Saw blade adjustable distance(up/down)(mm) | 0-120 | 0-250 |
| Saw blade adjustable distance(back/forth)(mm) | 0-200 | 0-250 |
| Max.stone thickness(mm) | 20-220 | 20-270 |
| Conveyor Belt Length*width*thickness(mm) | 5970*280*7 | 6800*400*7 |
| Conveyor Belt Speed(Adjustable)(mm/min ) | 600-2450 | |
| Max.Cutting Depth(mm) | 280 | 350-450 |
For more information, pls contact me
Xiamen Bestlink Factory Co., Ltd.
Add: Unit 8001,No.350,Changle road,Huli,Xiamen China. 361006
Cell/ Whatsapp/ viber/ wechat:+86-13600966313 (Mr.Richard Chen)
Tel: +86-592-5601702 Fax:+86-592-5601703
E-mail: info@split-stone.com
http://split-stone.com
Skype: chenlaiyou
Website:
NATURAL STONE CUTTING: http://www.split-stone.com
ALIBABA: https://quarryingtools.en.alibaba.com
MADE-IN-CHINA: http://xmbestlink.en.made-in-china.com
FACEBOOK: https://www.facebook.com/quarryingtools
YOUTUBE: https://www.youtube.com/channel/UCRJ2...
TikTok: https://www.tiktok.com/@lisawang987
CE certificate of Thin Stone Veneer Saw
Patent certificate
factory site
project case
Delivery Time : Within 45 days after receiving your 50% down payment .
Payment term:50% by T/T in advance, balance by T/T before shipment
Warranty Period : One year except the wearing parts .
Loading space request:1*20ft container can load 2sets of VS-30,while VS-60 one set only.
Installation: If the buyer require a Chinese Technician to install the machines,the buyer need to pay for the following charges:
Ist: Return-tickets
2nd: Accommodation, including eating and living
3rd: Charge of Visa Applying
4th: Salary for technician: 120USD/Day
Shipping freight should be checked according the destination sea port name. if you need
any further information, please feel free to contact me.thanks.
